Name: CPC(D)40 Forklift
SKU: 0

English





PRODUCTS

CPC(D)40 Forklift

Product Description

BASIC TECHNICAL PARAMETERS	Unit	Parameters
Model		CPC-G40
Power type		diesel fuel
Lift capacity	(kg)	4000
Load center distance	(mm)	500
Battery(Voltage/Capacity)	(V/Ah)	12/80
PERFORMANCE PARAMETERS	Unit	Parameters
Max.lift height	(mm)	3000
Free lift height	(mm)	160
Mast tilt angle (front/rear)	(°)	6/12
Max.lift speed(full load/no load)	(mm/s)	420/440
Max.lowering speed(full load/no load)	(mm/s)	330/310
Max.travelling speed(full load/no load)	(km/h)	19/19.5
Min.turning radius	(mm)	2730
Gradeability(full load/no load)	(%)	15/20
Max.traction force	(KN)	25
Overweight	(kg)	5200
DIMENSIONS	Unit	Parameters
Length(without fork)	(mm)	2960
Width	(mm)	1400
Height of mast	(mm)	2130
Overall height (overhead guard)	(mm)	2160
Height of load-backrest	(mm)	1350
Overall height at max.lift	(mm)	4230
Min.ground clearance	(mm)	140
Wheel base	(mm)	1900
Front wheel tread	(mm)	1150
Rear wheel tread	(mm)	1070
Front overhang	(mm)	500
Rear overhang	(mm)	580
OTHER PARAMETERS	Unit	Parameters
Front tires		250-15-16PR
Rear tires		7.00-12-12PR
Fork size(LWH)	(mm)	107015050
ENGINES	Unit	Parameters
Engine model		All-diesel V32-50C45
Rated power	(kw/rpm)	36.8/2500
Rated torque	(N.m/rpm)	200/1600-1800
Number of cylinders		4
Displacement	(L)	3.17
