S360 Skid steer loaders

›

‹

›

Product Description

The S360 is a wheeled skid-steer loader designed for compactness and rapid maneuverability. Powered by a 14 hp engine and featuring a 280 kg rated load capacity, a 0.12 m³ bucket, and a standard travel speed of 6 km/h, it excels in space-constrained environments requiring frequent turning and short-distance transport. Its radial-lift design, 8.9-second cycle time, and 170 bar system relief pressure balance fundamental loading efficiency with operational responsiveness; meanwhile, its dimensions—an overall length of 2,200 mm (with bucket), a machine width of 800 mm, and a standard bucket width of 860 mm—strike an ideal balance between compact size and operational reach.


S360 Skid steer loaders

S360 Skid steer loaders

S360 Skid steer loaders


PERFORMANCE

S360

Engine Power

14

Speed- standard

6

Tubeless tires

500-8

Solid tires optional

500-8

Rated loading capacity

280

Lifting type

Radial lift

Total cycle time

8.9

Bucket capacity

0.12

System pressure

170

Hydraulic pump output flow

38

Starting battery

12V

Hydraulic oil tank

25

Fuel tank

6

Wight without bucket

620

Dimension

Parameter

Overall operating height

2460

Height to bucket hinge pin

1980

Height to top of cab

1320

Height to bottom of level bucket

1860

Overall length without bucket

1730

Overall length with bucket

2200

Dumping angle at maximum height

40

Dumping height

2336

Dumping Distance

530

Rollback of bucKet on ground

30

Rollback of bucKet at full heirht

98

Wheelbase

—

Ground clearance

150

Angle of departure

26

Turning radius front without bucket

760

Front turning radius with bucket

—

Rear turning radius

—

Troad width, center line to center line

760

Width between outside of two wheels

800

Bucket width

860
