| BASIC TECHNICAL PARAMETERS | Unit | Parameters |
| Model |
| CPD-GE50X |
| Power Type |
| electric |
| Voltage Platform | V | 80 |
| Operation Type |
| Vehicle |
| PERFORMANCE | Unit | Parameters |
| Rated load capacity | kg | 5000 |
| Load center distance | mm | 500 |
| Front overhang | mm | 560 |
| Rear overhang | mm | 560 |
| Wheelbase | mm | 2100 |
| Service weight (with / without battery) | kg | 6700/6400 |
| Axle load, fully loaded (front / rear) | kg | 10500/1200 |
| Axle load, unladen (front / rear) | kg | 2890/3810 |
| DIMENSIONS | Unit | Parameters |
| Tire type |
| Pneumatic tire |
| Number of wheels (x = drive wheels) |
| 2x/2 |
| Front tire size |
| 300-15-18PR |
| Rear tire size |
| 7.00-12-12PR |
| Front wheel track | mm | 1195 |
| Rear wheel track | mm | 1195 |
| Mast tilt (forward / backward) | ° | 6/12 |
| Mast lowered height | mm | 2275 |
| Free lift | mm | 160 |
| Maximum lift height | mm | 3000 |
| Maximum operating height | mm | 4280 |
| Overhead guard height | mm | 2280 |
| Truck length (to fork face) | mm | 3220 |
| Truck width | mm | 1500 |
| Fork dimensions (thickness × width × length) | mm | 1070×150×50 |
| Fork spread (outer edges) (min. / max.) | mm | 310-1350 |
| Mast ground clearance (fully loaded) | mm | 170 |
| Minimum chassis ground clearance | mm | 210 |
| Minimum turning radius | mm | 2930 |
| Maximum travel speed (fully loaded / unloaded) | km/h | 15/17 |
| Maximum lifting speed (fully loaded / unloaded) | mm/s | 300/430 |
| Lowering speed (fully loaded / unloaded) | mm/s | 480/380 |
| Maximum drawbar pull (fully loaded / unloaded) | N | 27000 |
| Gradeability (fully loaded / unloaded) | % | 18/25 |
| OTHER PARAMETERS | Unit | Parameters |
| Service brake (mechanical, electronic, hydraulic) |
| Hydraulic-pedal type |
| Parking brake (mechanical, electronic, hydraulic) |
| Mechanical—Manual |
| Traction motor rated power, S2 60-minute duty cycle | kW | 23AC |
| Oil pump motor rated power, S3 15-minute duty cycle | kW | 30AC |
| Motor type / Protection class |
| AC Asynchronous | IP54 |
| MOTOR AND CONTROLLER | Unit | Parameters |
| Battery type |
| Lithium iron phosphate battery |
| Standard battery voltage / capacity | V/Ah | 76.8/404 (460/608/808) |
| Standard battery weight | kg | 300 |
| Battery heating method / Protection rating |
| Low-temperature electric heating / IP54 |
| MCU motor controller type |
| MOSFET/AC |
| Hydraulic system operating pressure | Mpa | 19 |
